150L/min · 220V Desktop Spot Welding System — VCM Enameled Wire Resistance Welding System

Product overview

This desktop spot welding system combines a VCM (Voice coil motor) drive for accurate pulse timing, a transistor‑based power stage for clean energy delivery, and a 150 L/min cooling provision to manage thermal accumulation on enamelled wire and small conductors. The compact 220 V design fits benchtop R&D and small production cells. Features include programmable pulse profiles, adjustable electrode force, multi‑pulse modes, optional weld monitoring and quick electrode changeover for high‑mix production.

Problem → Cause → Solution

Problem: Welding enameled wire or fine conductors often causes insulation burn, inconsistent joints or conductor breakage, leading to assembly failures.
Cause: Excessive energy, insufficient cooling, imprecise pulse timing and inconsistent contact force lead to insulation damage and variable weld quality.
Solution: The system uses precise VCM timing and transistor current shaping with controlled electrode force and active 150 L/min cooling to limit peak temperature, protect enamel insulation and produce consistent resistance welds. Validate profiles with sample testing and store recipes for repeatable production.

Technical Specifications

Applications

• Enameled wire terminal welding in micro motor, speaker voice coil and sensor assemblies.
• Fine conductor joining in coil winding, transformer winding and precision electromechanical components.
• R&D and small‑batch production where benchtop welding with active cooling and traceability is required.

How it works

Recipe selection: load material preset or create a custom profile (current, pulse width, electrode force, pulses).
Electrode contact & force: actuator applies controlled force to ensure consistent contact resistance.
Pulse delivery: VCM timing and transistor power stage deliver shaped pulses per profile.
Cooling & monitoring: 150 L/min cooling reduces peak temperature; optional weld monitoring logs current/voltage traces for QA.

How to choose

Wire gauge & insulation: select pulse energy and electrode tips matched to wire gauge and enamel type; start with manufacturer presets and run sample validation.
Cooling needs: use 150 L/min cooling for continuous runs or higher duty cycles; consider liquid cooling for dense assemblies.
Pulse resolution: choose sub‑ms capable units when welding very fine wires to avoid insulation burn.
Electrode selection: small‑diameter copper tips for fine wires; plated/tungsten tips for high wear.
Traceability: enable weld monitoring if batch documentation and SPC are required.

FAQ

Q: What wire gauges are supported?
A: Typical supported range is AWG 40–18 (≈0.08–1.0 mm) depending on material and electrode; confirm with sample testing.
Q: How does the 150 L/min cooling help?
A: Active cooling lowers peak temperature between pulses and during continuous runs, reducing enamel degradation and improving joint consistency.
Q: Can weld data be logged for traceability?
A: Yes—optional weld monitoring records current/voltage traces and exports batch logs for SPC or MES integration.

Contact Us

Boost your VCM coil assembly quality and production efficiency with the DW200P precision spot welding system.
Contact us today for detailed quotations, technical support, and customized solutions tailored to your production needs.
