| Brand Name: | Mingseal |
| Model Number: | KSV1000-R |
| MOQ: | 1set |
| Price: | $4000-$10000 / pcs |
| Delivery Time: | 5-60days |
| Payment Terms: | L/C,D/A,D/P,T/T,Western Union |
| Parameter | Specification |
|---|---|
| Work type | Screw type |
| Work mode | Timing, linkage |
| Rotator speed range | 10~500 rpm |
| Glues range | 5000-500000 cps |
| Trigger to dispense | Shot button, trigger interface (24V active & passive) |
| External output signal | In-discharging output, fault output |
| Other functions | Instant suction, RS-232C communication, Chinese & English display switching |
| Stator material | Stainless steel |
| Screw material | Tungsten steel |
| Valve dimension (W/O trigger cords) | 37 * 230 * 85mm (WHD) |
| Controller dimension (main body) | 240 * 100 * 260mm (WHD) |
